Due to outlet water up to 60C, the unit can replace the traditional boilers which are applied to the house heating and domestic
hot water.
Intensive protections have been added to Nulite NEW ENERGY EVI Air to Water Heat Pump in order to make the units run safely.Protections for high discharging temperature, high vacuum degrees excess current and large temperature difference are reinforced in EVI Heat Pump.
Details Images
Nulite NEW ENERGY EVI Air Source Heat Pump -25C Degrees
Products Description
Enhanced Vapor Injection
1.EVI compressor special designed for high water temperature 60 degrees.
2.Base frame and external panels made of galvanized powder coated steel.
3.Exchanger equipped with high efficiency shell in tube heat exchanger.
4.Work under the temperature -25°C stably with good COP, by adopting the super EVI tech.
2.Base frame and external panels made of galvanized powder coated steel.
3.Exchanger equipped with high efficiency shell in tube heat exchanger.
4.Work under the temperature -25°C stably with good COP, by adopting the super EVI tech.
5.High efficiency compressor with R407C refrigerant. 6.Fully sealed control box with water proof level IPX4. 7.Intelligent controller and adjustment by intelligent microprocessor. 8.Thermostatic heating element for evaporator anti-frosting protection. 9.Electrical expansion valve. 10.Automatic defrosting function included.
Creative and Detail-oriented
*Adapting intelligent temperature compensation technology,the unit can adjust the setting temperature according to the amibent temperature to povide hot water with comfortable temperature for you!
*The EVI compressor ensures the unit operate safely at low ambient temp. with high effeciency and low noise.
NO.1 COP up to 4.4
Working condition,adopting Copeland scroll type compressor.
The application of EVI technology together with high efficiency heat exchanger can improve the heat exchanging rate and make the COP up to 4.4.
NO.2 Highest outlet water temp. 60C
Due to outlet water up to 60C, the unit can replace the traditional boilers which are applied to the house heating and domestic
hot water.
NO.3 Intensive Protections
Intensive protections have been added to Nulite NEW ENERGY EVI Air to Water Heat Pump in order to make the units run safely.Protections for high discharging temperature, high vacuum degrees excess current and large temperature difference are reinforced in EVI Heat Pump.
Product Paramenters
|
Item
|
|
|
NERS-B3S-D
|
NERS-B4S-D
|
NERS-B5S-D
|
NERS-G10D
|
||||
|
Rated heating capicity
|
|
KW
|
10.4
|
15.5
|
19.7
|
38.5
|
||||
|
Input power
|
|
KW
|
2.38
|
3.83
|
4.69
|
9.38
|
||||
|
Voltage
|
|
V/Hz/Ph
|
220/50/1
380/50/3 |
380/50/3
|
380/50/3
|
380/50/3
|
||||
|
Rated current
|
|
A
|
11/3.7
|
5.8
|
8.4
|
16.8
|
||||
|
Rated output water temperature
|
|
°C
|
Max temp.: 55-60°C
|
|
|
|
||||
|
Hot water ouput
|
|
L/H
|
250
|
380
|
420
|
830
|
||||
|
Refrigeration
|
|
|
R407C
|
|
|
|
||||
|
Control mode
|
|
|
Microcomputer central processor (LCD control panel)
|
|
|
|
||||
|
Compressor
|
Form
|
|
Scroll type
|
|
|
|
||||
|
|
Quantity
|
|
1
|
1
|
1
|
2
|
||||
|
|
Brand
|
|
Copeland
|
|
|
|
||||
|
Unit
|
Net size
|
mm
|
1105×452×904
|
1108x489x1257
|
1108x489x1257
|
1507*853*1350
|
||||
|
|
Weight
|
Kg
|
98
|
160
|
165
|
345
|
||||
|
|
Nosie level
|
dB(A)
|
≤50
|
≤55
|
≤55
|
≤64.5
|
||||
|
Fan
|
Form
|
|
internal rotor motor, magnesium aluminum alloy leaves(low noise)
|
|
|
|
||||
|
|
Fan power
|
W
|
250
|
370
|
370
|
500*2
|
||||
|
Ambient temperature
|
|
°C
|
(-25℃ — 43℃)
|
|
|
|
||||
|
Inlet pipe diameter
|
|
|
DN20
|
DN25
|
DN25
|
DN40
|
||||
|
Outlet pipe diameter
|
|
|
DN20
|
DN25
|
DN25
|
DN40
|
||||
